argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor Class Reference

#include <colored_blob_omnidirectional_camera_rotzonly_sensor.h>

Inheritance diagram for argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor:
Collaboration diagram for argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor:

Public Member Functions

 CColoredBlobOmnidirectionalCameraRotZOnlySensor ()

virtual ~CColoredBlobOmnidirectionalCameraRotZOnlySensor ()

virtual void SetRobot (CComposableEntity &c_entity)
 Sets the entity associated to this sensor. More...

virtual void Init (TConfigurationNode &t_tree)
 Initializes the sensor from the XML configuration tree. More...

virtual void Update ()
 Updates the state of the entity associated to this sensor. More...

virtual void Reset ()
 Resets the sensor to the state it had just after Init(). More...

virtual void Destroy ()
 Destroys the sensor. More...

virtual void Enable ()
 Enables image acquisition and processing. More...

virtual void Disable ()
 Disables image acquisition and processing. More...

- Public Member Functions inherited from argos::CCI_ColoredBlobOmnidirectionalCameraSensor
 CCI_ColoredBlobOmnidirectionalCameraSensor ()
 Constructor. More...

virtual ~CCI_ColoredBlobOmnidirectionalCameraSensor ()
 Destructor. More...

const SReadingsGetReadings () const
 Returns a reference to the current camera readings. More...

- Public Member Functions inherited from argos::CCI_Sensor
virtual ~CCI_Sensor ()
 Class destructor. More...

- Public Member Functions inherited from argos::CBaseConfigurableResource
virtual ~CBaseConfigurableResource ()
 Class destructor. More...

- Public Member Functions inherited from argos::CSimulatedSensor
virtual ~CSimulatedSensor ()
 Class destructor. More...


Protected Attributes

bool m_bEnabled

COmnidirectionalCameraEquippedEntitym_pcOmnicamEntity

CControllableEntitym_pcControllableEntity

CEmbodiedEntitym_pcEmbodiedEntity

CPositionalIndex< CLEDEntity > * m_pcLEDIndex

CPositionalIndex< CEmbodiedEntity > * m_pcEmbodiedIndex

COmnidirectionalCameraLEDCheckOperationm_pcOperation

bool m_bShowRays

- Protected Attributes inherited from argos::CCI_ColoredBlobOmnidirectionalCameraSensor
SReadings m_sReadings


Additional Inherited Members

- Public Types inherited from argos::CCI_ColoredBlobOmnidirectionalCameraSensor
typedef std::vector< SBlob * > TBlobList
 Vector of pointers to colored blobs. More...

- Public Types inherited from argos::CCI_Sensor
typedef std::map< std::string, CCI_Sensor *, std::less< std::string > > TMap


Detailed Description

Constructor & Destructor Documentation

argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::CColoredBlobOmnidirectionalCameraRotZOnlySensor ( )
argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::~CColoredBlobOmnidirectionalCameraRotZOnlySensor ( )
virtual

Member Function Documentation

void argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::Destroy ( )
virtual

Destroys the sensor.

This method is supposed to undo whatever was done in Init(). The default implementation of this method does nothing.

See also
Init()
Reset()

Reimplemented from argos::CCI_Sensor.

Definition at line 214 of file colored_blob_omnidirectional_camera_rotzonly_sensor.cpp.

void argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::Disable ( )
virtual

Disables image acquisition and processing.

Implements argos::CCI_ColoredBlobOmnidirectionalCameraSensor.

Definition at line 229 of file colored_blob_omnidirectional_camera_rotzonly_sensor.cpp.

void argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::Enable ( )
virtual

Enables image acquisition and processing.

Implements argos::CCI_ColoredBlobOmnidirectionalCameraSensor.

Definition at line 221 of file colored_blob_omnidirectional_camera_rotzonly_sensor.cpp.

void argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::Init ( TConfigurationNode t_node)
virtual

Initializes the sensor from the XML configuration tree.

The default implementation of this method does nothing.

Parameters
t_nodeThe XML configuration tree relative to this sensor.
See also
Reset()
Destroy()

Reimplemented from argos::CCI_Sensor.

Definition at line 153 of file colored_blob_omnidirectional_camera_rotzonly_sensor.cpp.

void argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::Reset ( )
virtual

Resets the sensor to the state it had just after Init().

The default implementation of this method does nothing.

See also
Init()
Destroy()

Reimplemented from argos::CCI_Sensor.

Definition at line 206 of file colored_blob_omnidirectional_camera_rotzonly_sensor.cpp.

void argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::SetRobot ( CComposableEntity c_entity)
virtual

Sets the entity associated to this sensor.

When a controller is created, all the sensors and actuators are created, too. This function is called right before the Init() method of the sensor is called.

Parameters
c_entityThe entity to associate to this sensor.
See also
CComposableEntity
CControllableEntity::SetController()
CCI_Sensor::Init()

Implements argos::CSimulatedSensor.

Definition at line 141 of file colored_blob_omnidirectional_camera_rotzonly_sensor.cpp.

void argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::Update ( )
virtual

Updates the state of the entity associated to this sensor.

Implements argos::CSimulatedSensor.

Definition at line 183 of file colored_blob_omnidirectional_camera_rotzonly_sensor.cpp.

Member Data Documentation

bool argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::m_bEnabled
protected
bool argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::m_bShowRays
protected
CControllableEntity* argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::m_pcControllableEntity
protected
CEmbodiedEntity* argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::m_pcEmbodiedEntity
protected
CPositionalIndex<CEmbodiedEntity>* argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::m_pcEmbodiedIndex
protected
CPositionalIndex<CLEDEntity>* argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::m_pcLEDIndex
protected
COmnidirectionalCameraEquippedEntity* argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::m_pcOmnicamEntity
protected
COmnidirectionalCameraLEDCheckOperation* argos::CColoredBlobOmnidirectionalCameraRotZOnlySensor::m_pcOperation
protected
