argos::CFootBotGripperDefaultActuator Class Reference

#include <footbot_gripper_default_actuator.h>

Inheritance diagram for argos::CFootBotGripperDefaultActuator:
Collaboration diagram for argos::CFootBotGripperDefaultActuator:

Public Member Functions

 CFootBotGripperDefaultActuator ()

virtual ~CFootBotGripperDefaultActuator ()

virtual void SetRobot (CComposableEntity &c_entity)
 Sets the entity associated to this actuator. More...

virtual void Update ()
 Updates the state of the entity associated to this actuator. More...

virtual void Reset ()
 Resets the actuator to the state it had just after Init(). More...

virtual void EnableCheckForObjectGrippedRoutine ()
 Enables the ASEBA routine that checks for a gripped object each time the gripper is opened. More...

virtual void DisableCheckForObjectGrippedRoutine ()
 Disables the ASEBA routine that checks for a gripped object each time the gripper is opened. More...

- Public Member Functions inherited from argos::CSimulatedActuator
virtual ~CSimulatedActuator ()
 Class destructor. More...

- Public Member Functions inherited from argos::CCI_FootBotGripperActuator
 CCI_FootBotGripperActuator ()
 Class constructor. More...

virtual ~CCI_FootBotGripperActuator ()
 Class destructor. More...

void SetAperture (const CRadians &c_aperture)
 Sets the gripper aperture. More...

void LockPositive ()
 Sets gripper aperture to lock, positive direction. More...

void LockNegative ()
 Sets gripper aperture to lock, negative direction. More...

void Unlock ()
 Unlock gripper: objects are released. More...

- Public Member Functions inherited from argos::CCI_Actuator
virtual ~CCI_Actuator ()
 Class destructor. More...

virtual void Init (TConfigurationNode &t_node)
 Initializes the actuator from the XML configuration tree. More...

virtual void Destroy ()
 Destroys the actuator. More...

- Public Member Functions inherited from argos::CBaseConfigurableResource
virtual ~CBaseConfigurableResource ()
 Class destructor. More...


Additional Inherited Members

- Public Types inherited from argos::CCI_Actuator
typedef std::map< std::string, CCI_Actuator *, std::less< std::string > > TMap

- Static Public Attributes inherited from argos::CCI_FootBotGripperActuator
static CRadians UNLOCKED

static CRadians LOCKED_POSITIVE

static CRadians LOCKED_NEGATIVE

- Protected Attributes inherited from argos::CCI_FootBotGripperActuator
CRadians m_cAperture


Detailed Description

Definition at line 23 of file footbot_gripper_default_actuator.h.

Constructor & Destructor Documentation

argos::CFootBotGripperDefaultActuator::CFootBotGripperDefaultActuator ( )

Definition at line 16 of file footbot_gripper_default_actuator.cpp.

virtual argos::CFootBotGripperDefaultActuator::~CFootBotGripperDefaultActuator ( )
inlinevirtual

Definition at line 30 of file footbot_gripper_default_actuator.h.

Member Function Documentation

virtual void argos::CFootBotGripperDefaultActuator::DisableCheckForObjectGrippedRoutine ( )
inlinevirtual

Disables the ASEBA routine that checks for a gripped object each time the gripper is opened.

Implements argos::CCI_FootBotGripperActuator.

Definition at line 38 of file footbot_gripper_default_actuator.h.

virtual void argos::CFootBotGripperDefaultActuator::EnableCheckForObjectGrippedRoutine ( )
inlinevirtual

Enables the ASEBA routine that checks for a gripped object each time the gripper is opened.

Implements argos::CCI_FootBotGripperActuator.

Definition at line 37 of file footbot_gripper_default_actuator.h.

void argos::CFootBotGripperDefaultActuator::Reset ( )
virtual

Resets the actuator to the state it had just after Init().

The default implementation of this method does nothing.

See also
Init()
Destroy()

Reimplemented from argos::CCI_Actuator.

Definition at line 37 of file footbot_gripper_default_actuator.cpp.

void argos::CFootBotGripperDefaultActuator::SetRobot ( CComposableEntity c_entity)
virtual

Sets the entity associated to this actuator.

When a controller is created, all the sensors and actuators are created, too. This function is called right before the Init() method of the actuator is called.

Parameters
c_entityThe entity to associate to this actuator.
See also
CComposableEntity
CControllableEntity::SetController()
CCI_Actuator::Init()

Implements argos::CSimulatedActuator.

Definition at line 22 of file footbot_gripper_default_actuator.cpp.

void argos::CFootBotGripperDefaultActuator::Update ( )
virtual

Updates the state of the entity associated to this actuator.

Implements argos::CSimulatedActuator.

Definition at line 30 of file footbot_gripper_default_actuator.cpp.
