argos::CSpaceHash< ENTITY, UPDATER > Class Template Reference

Defines the basic space hash. More...

#include <space_hash.h>

Inheritance diagram for argos::CSpaceHash< ENTITY, UPDATER >:
Collaboration diagram for argos::CSpaceHash< ENTITY, UPDATER >:

Public Member Functions

virtual void Update ()
 Updates the entire space hash. More...

- Public Member Functions inherited from argos::CAbstractSpaceHash< ENTITY >
 CAbstractSpaceHash ()
 Class constructor. More...

virtual ~CAbstractSpaceHash ()
 Class destructor. More...

virtual void AddEntity (ENTITY &c_entity)
 Adds an entity to the space hash. More...

TEntityListGetEntities ()
 Returns the list of entities held by this space hash. More...

virtual void RemoveEntity (ENTITY &c_entity)
 Remove an entity from the space hash. More...

size_t GetSize ()
 Returns the size of the space hash. More...

virtual void SetSize (size_t un_size)
 Sets the size of the space hash. More...

CVector3GetCellSize ()
 Returns the size of the cells of the space hash. More...

CVector3GetInvCellSize ()
 Returns the inverse size of the cells of the space hash. More...

virtual void SetCellSize (const CVector3 &c_cell_size)
 Sets the size of the cells of the space hash. More...

virtual void UpdateCell (SInt32 n_x, SInt32 n_y, SInt32 n_z, ENTITY &c_entity)=0
 Adds an entity to a cell of the space hash. More...

virtual SInt32 SpaceToHashTable (Real f_coord, UInt32 un_axis)
 Converts a single space coordinate into a space hash cell coordinate. More...

virtual Real HashTableToSpace (SInt32 n_coord, UInt32 un_axis)
 Converts a single space hash cell coordinate into a space coordinate. More...

virtual void SpaceToHashTable (SInt32 &n_i, SInt32 &n_j, SInt32 &n_k, const CVector3 &c_pos)
 Converts a space position into a space hash cell The values are written into n_i, n_j, and n_k. More...

virtual bool CheckCell (SInt32 n_i, SInt32 n_j, SInt32 n_k, TEntityList &t_entities)=0
 Looks for entities to process in a cell. More...

virtual void Dump (CARGoSLog &c_os)=0

- Public Member Functions inherited from argos::CPositionalIndex< ENTITY >
 CPositionalIndex ()

virtual ~CPositionalIndex ()

virtual void Init (TConfigurationNode &t_tree)=0
 Initializes the resource. More...

virtual void Reset ()=0
 Resets the resource. More...

virtual void Destroy ()=0
 Undoes whatever was done by Init(). More...

virtual void GetEntitiesAt (CSet< ENTITY *, SEntityComparator > &c_entities, const CVector3 &c_position) const =0
 Puts the entities located at the given point in the passed buffer. More...

virtual void ForAllEntities (COperation &c_operation)=0
 Executes an operation on all the indexed entities. More...

virtual void ForEntitiesInSphereRange (const CVector3 &c_center, Real f_radius, COperation &c_operation)=0
 Executes an operation on all entities within the specified sphere range. More...

virtual void ForEntitiesInBoxRange (const CVector3 &c_center, const CVector3 &c_half_size, COperation &c_operation)=0
 Executes an operation on all entities within the specified box range. More...

virtual void ForEntitiesInCircleRange (const CVector3 &c_center, Real f_radius, COperation &c_operation)=0
 Executes an operation on all entities within the specified circle range. More...

virtual void ForEntitiesInRectangleRange (const CVector3 &c_center, const CVector2 &c_half_size, COperation &c_operation)=0
 Executes an operation on all entities within the specified rectangle range. More...

virtual void ForEntitiesAlongRay (const CRay3 &c_ray, COperation &c_operation, bool b_stop_at_closest_match=false)=0
 Executes an operation on all entities that intersect the given ray. More...


Additional Inherited Members

- Public Types inherited from argos::CAbstractSpaceHash< ENTITY >
typedef CSet< ENTITY * > TEntityList
 Type definition for the list of entities held by the space hash. More...

- Protected Member Functions inherited from argos::CAbstractSpaceHash< ENTITY >
UInt32 CoordinateHash (SInt32 n_i, SInt32 n_j, SInt32 n_k)
 Calculates the hash of a space hash coordinate. More...


Detailed Description

template<class ENTITY, class UPDATER>
class argos::CSpaceHash< ENTITY, UPDATER >

Defines the basic space hash.

If you want to create a new space hash implementation, you need to extend this class.

Parameters
ENTITYThe type of entity held by the corresponding space hash
UPDATERThe cell updater for type ENTITY
See also
CSpaceHashNative

Definition at line 300 of file space_hash.h.

Member Function Documentation

template<class ENTITY, class UPDATER>
virtual void argos::CSpaceHash< ENTITY, UPDATER >::Update ( )
inlinevirtual

Updates the entire space hash.

It calls the updater for all the entities held by the space hash.

See also
CSpaceHashUpdater

Implements argos::CAbstractSpaceHash< ENTITY >.

Reimplemented in argos::CSpaceHashNative< Element, Updater >.

Definition at line 309 of file space_hash.h.
