#include <ci_leds_actuator.h>
Public Types | |
| typedef std::vector< CColor > | TSettings |
 Public Types inherited from argos::CCI_Actuator | |
| typedef std::map< std::string, CCI_Actuator *, std::less< std::string > > | TMap |
Public Member Functions | |
| CCI_LEDsActuator () | |
| virtual | ~CCI_LEDsActuator () |
| size_t | GetNumLEDs () const |
| Returns the number of LEDs. More... | |
| virtual void | SetSingleColor (UInt32 un_led_number, const CColor &c_color) |
| Sets the color of a single LED. More... | |
| virtual void | SetAllColors (const CColor &c_color) |
| Sets the color of the whole LED ring. More... | |
| virtual void | SetAllColors (const TSettings &c_colors) |
| Sets the color of the whole LED ring. More... | |
| virtual void | SetSingleIntensity (UInt32 un_led_number, UInt8 un_intensity) |
| Sets the intensity of a single LED in the ring. More... | |
| virtual void | SetAllIntensities (UInt8 un_intensity) |
| Sets the intensity of all the LEDs in the ring. More... | |
| Public Member Functions inherited from argos::CCI_Actuator | |
| virtual | ~CCI_Actuator () |
| Class destructor. More... | |
| virtual void | Init (TConfigurationNode &t_node) |
| Initializes the actuator from the XML configuration tree. More... | |
| virtual void | Reset () |
| Resets the actuator to the state it had just after Init(). More... | |
| virtual void | Destroy () |
| Destroys the actuator. More... | |
| Public Member Functions inherited from argos::CBaseConfigurableResource | |
| virtual | ~CBaseConfigurableResource () |
| Class destructor. More... | |
Protected Attributes | |
| TSettings | m_tSettings |
Detailed Description
Definition at line 19 of file ci_leds_actuator.h.
Member Typedef Documentation
◆ TSettings
| typedef std::vector<CColor> argos::CCI_LEDsActuator::TSettings |
Definition at line 23 of file ci_leds_actuator.h.
Constructor & Destructor Documentation
◆ CCI_LEDsActuator()
|
inline |
Definition at line 27 of file ci_leds_actuator.h.
◆ ~CCI_LEDsActuator()
|
inlinevirtual |
Definition at line 29 of file ci_leds_actuator.h.
Member Function Documentation
◆ GetNumLEDs()
| size_t argos::CCI_LEDsActuator::GetNumLEDs | ( | ) | const |
Returns the number of LEDs.
Definition at line 101 of file ci_leds_actuator.cpp.
◆ SetAllColors() [1/2]
|
virtual |
Sets the color of the whole LED ring.
All the LEDs in the ring will be lit up in the same color. The method does not impact on the LED intensity: if the intensity was changed, the method updates the color but preserves the intensity previously set.
- Parameters
-
c_color color to set
Definition at line 116 of file ci_leds_actuator.cpp.
◆ SetAllColors() [2/2]
|
virtual |
Sets the color of the whole LED ring.
All the LEDs in the ring will be lit up, it is possible to have a different color for each LED. Notice that the method also impacts on the intensity of the LED color: it is up to the user to modulate the alpha channel of the color if intensity reduction is needed.
- Parameters
-
c_colors color to set for each LED.
Definition at line 125 of file ci_leds_actuator.cpp.
◆ SetAllIntensities()
|
virtual |
Sets the intensity of all the LEDs in the ring.
Intensity is expressed in [0-255].
- Parameters
-
un_intensity color to set for each LED.
Definition at line 140 of file ci_leds_actuator.cpp.
◆ SetSingleColor()
|
virtual |
Sets the color of a single LED.
The method does not impact on the LED intensity: if the intensity was changed, the method updates the color but preserves the intensity previously set.
- Parameters
-
un_led_number LED that must be set c_color color to set
Definition at line 108 of file ci_leds_actuator.cpp.
◆ SetSingleIntensity()
|
virtual |
Sets the intensity of a single LED in the ring.
Intensity is expressed in [0-255].
- Parameters
-
un_led_number index of the LED whose intensity must be set. un_intensity color to set for each LED.
Definition at line 132 of file ci_leds_actuator.cpp.
Member Data Documentation
◆ m_tSettings
|
protected |
Definition at line 93 of file ci_leds_actuator.h.
